CIOKS AC10 Power Supply

Description

If your pedalboard requires both AC and DC power, then the CIOKS AC10 Pedal Power Supply is just what you need! This power supply offers 10 outlets in six isolated sections with more than enough juice to power your hungriest pedals. You get a total of six DC outlets in addition to four AC outlets with different voltage options. Before the power is delivered through the outlets, the CIOKS AC10 first filters the power through its shielded toroidal transformer, ensuring your pedals get the cleanest, quietest power possible. To keep you on top everything, each outlet has a nearby metering LED to monitor each effect's power status in the chain. The CIOKS AC10 comes complete with 17 Flex cables and mounting hardware for Pedaltrain and Temple Audio Pedalboards.

Included Flex Cables

• 8 x Standard Flex Type 1 — 5.5mm/2.1mm center-negative DC plug, black
• 1 x Standard Flex Type 2 — 5.5mm/2.1mm center-positive DC plug, red
• 2 x Standard Flex Type 4 — 5.5mm/2.5mm center-positive DC plug, green
• 1 x Standard Flex Type 5 — 3.5mm tip positive jack plug, black
• 1 x Standard Flex Type 6 — 9-volt battery clip, black
• 1 x Standard Flex Type 7 — 2-pin DIN plug, blue
• 1 x Split Flex Type 1 — powers two pedals from one outlet, black
• 1 x Stack Flex Type 1 — adds voltages of two outlets, white/black

Specifications

• Outlet 1-2: 9V DC / 100mA each
• Outlet 3-4: 9 or 12V DC / 200mA each
• Outlet 5-6: 9 and 12 or 15V DC / 600mA*
• Outlet 7-8: 9 or 12V AC / 800mA*
• Outlet 9-10: 9, 12 or 16V AC / 800mA

* only one of these two sections can be used

Size: 6.22" x 3.86" x 1.38" (excluding rubber feet)
Weight: 2.42 lbs
